Better Economical Performance
314Ah battery cell with 8000 life cycles; Each pack is independently managed by the module controller. If a single unit fails, the remaining units will not be affected; Pack-level charging and discharging management,enhancing cycle efficiency by 1%.
Higher Reliability
Maximum 30% automatic online bypass of failure battery cells;
IP66 for PCS, IP67 for battery pack, IP55 for battery cabinet;
Cooling system top configuration design.
Comprehensive Safety Protection
Issue a battery risk warning 20 days inadvance, preventing the risk of internalshort circuit;
Fuse design in PCS DC input, multiple safety protection for system over current;
Anti-explosion valve & aerosol FSS & firehydrant
interface design.
Excellent AC Performance
100% nominal power output @50°C;
100% unbalanced load ability, 3 phase +N configuration supports off-grid operation and single phase loaded;
Active power and reactive power decoupled control.
